Gas Valves

2-1/2 Gas Valve Body NO OVER TRAVEL Replaces:V710KES ***Obsolete - IMportant read information in internal notes.***

2 Way Normally Closed Gas Valve Body 3"npt or Flanged 160 Cv 8,627 cfh 0-15psi Die-cast Aluminum w/ Quick Opening Trim ***Obsolete - Important read information in internal notes.***

Combination Gas Valve 1/2 3/4 * Combination Gas Valve Pilot Safety And Pressure Regulator. 24V. .2 Amps 1/2 X 3/4 NPT. 250000 BTU Includes 3/4 X 1/2 Bushing

Pilot Gas Valve 1/4 NPT. 24V. 20000 BTU. 10 PSI. Max. Pressure. 14Va.

3/8 Pilot Gas Valve * Pilot Gas Valve 3/8 NPT. 24V. 67000 NPT. 10 PSI. Max. Pressure. 14Va.

1-1/2 Gas Solenoic Vlv 24v NC * Normally closed 1-1/2 inch gas solenoid. 2psi maximum pressure. 24vac.

1 Gas Valve 24V * Diaphragm Gas Valve 1 NPT. 24V. 1021000 BTU 1/2 PSI Max Pressure. 14Va Diaphragm Gas Valve, 1", 1021 Cfh Capacity, 1/2 Psi Pressure, 24Vac, Straight Through, 6" Leadwires, 1/8"-27 NPT Pilot Tapping, Upright Horizontal Mounting, 1/8"-27 NPT Bleed Tapping, 5 Second Maximum Valve Opening Timing, 2 Second Maximum Valve Closing Timing, 32-125 Degree Operating Temperature Range, Aluminum Body, Natural Gas, LP and Manufactured Gas

Gas Valve 24V 3/4 * Diaphragm Gas Valve 3/4 NPT. 24V. 668000 BTU. 1/2 PSI Max. Pressure. 14Va

1-1/4 Gas Valve 24V * Diaphragm Gas Valve 1-1/4 NPT. 24V 2100000 BTU. 1 PSI Max Pressure. 14Va

Gas Valve 24V 1-1/2 * Diaphragm Gas Valve 1-1/2 NPT. 24V. 2400000 BTU. 1 PSI Max. Pressure. 14Va

2 Gas Valve 24V * Diaphragm Gas Valve 2 NPT. 24V. 4178000 BTU. 1 PSI Max. Pressure. 14Va

1 Gas Valve 24V Two Stage * Two Stage Pressure Regulating Gas Valve. 24 Volts. 1 Npt. Rapid Opening.

2 stage diaphragm valve 1-1/4 * Two stage pressure regulating gas valve. 24 volts. 1-1/4 NPT. 480 to 1600 CFH. Low fire 0.8 to 2 in/wc, High fire 3 to 4.5 in/wc.

Replace Gas Valve Top Adj Reg * Replacement Gas Valve For G60CbA1 & 3 CbG134910111416 And 17 DbG1 QbG1234567 And 8 QbK1 QbL1 & 2 RbG1 & 2 RbK1 And 2 And RgL1. With Gas Pressure Regulator

Dual Valve Combo Gas Control * Combination Dual Seated Gas Valve. Pilot safety And Pressure Regulator. 24V Coil.5 Amp. 1/2 X 1/2 Or 1/2 X 3/4 NPT Using Adaptor. 130000 BTU. 0F Minimum Includes 1/2 X 3/8 Bushing.

Gas Valve 24V 1/2" X1/2" Slow-Opening Gas Valve w/ 3/4" Add-On Flange, & 1/2" x 3/8" Red. Bushing, w/ LP Kit Replaces: Carrier OEM VR8200H2002

Direct Ignition 1/2" Gas valve 3.5" wc Standard opening. -40 to 175F, compact 2.3" swing radius.

Direct Ignition 1/2" Slow Opening Gas Valve 3.5"wc, -40 to 175F, compact 2.3" swing radius.

1/2 Univ Elec Gas Valve 24V * Universal Electronic gas valve. 1/2 NPT. 24 volts. Standard opening. Intermittent pilot, Direct Spark or Hot surface ignotion. 150 CFH @ 1 in drop.

Combination Gas Control * Combination Gas Valve. 24V. Standing Pilot. 190 CFH. Regulator Set @ 3.5 Nat. Or Lp Gas. 1/2 X 3/4 With One 1/2 Reducer Bushing.

3/4X3/4 3.5 Wc W 393691 Lp Ki * Combination Gas Valve. 24V. Standing Pilot. 200 CFH. Inlet 3/4 Outlet 3/4 Nat Or Lp Gas. 3.5 Regulator .

Standing Pilot Combo Gas Valve Step-Open Step Open Standing pilot combination gas valve. Redundant. 24 volts. Step opening. 3/4 NPT with two 3/4X1/2 reducer bushings. Maximum inlet 1/2 PSI. 30 to 300 CFH.

Redundant Gas Vlv 3/4 Slow Opn * Combination Gas Valve. 24V. Standing Pilot. Slow Opening. 200 CFH. Regulator 3.5 . Natural Or Lp Gas. Inlet 3/4 Outlet 3/4 .

24vac 3/4 standing pilot combination valve, 3.5" water column, standard opening, single stage, straight through with flange, 30000 btu to 290000 btu max, 1/2# pressure rating, 1/8" npt pressure tap with plug, includes 3/4x1/2"reducer bushings (2), q340 thermocouple, natural to lp conversion kit
