Humidity Controls

Manual humidifier control 24V * Manual humidifier control. SPST switch. Range 15 to 45% RH. Foam gasket for mounting to return duct. Can be wall mounted.

Electronic Humidistat 24 volts.

Relative Humidity, RH Outputs: 0-5, 0-10 VDC & 4-20mA (Default), Duct, ± 3% Accuracy, 20,000 Ohm Thermistor, Euro Enclosure

Humidity sensor 4-20 mA * Humidity sensor. Range 10 to 90% relative humidity. 4 to 20 mA direct acting output. Two wire. Power supply 12 to 40 VDC.

Lyric water Leak and Freeze Detector detects water with sensors on base of unit or has expanded coverage w/ included 4' sensing cable. Includes 3 AAA batteries that lkast up to 3 years. Runs on WiFi and Lyric platform. Does not require Lyric thermostat. Sends out notification messages on an alarnm. Integral 100 dB alarm. Can be used w/ CHWES41013/U 4" extension cable for additional sensing area.

Lyric Water Leak and Freeze Detector extension cable, 4' lenght. Used for extending sensing lenght of CHW3610W1001 detector.Multiple cables can be plugged together for a maximum of 500' sensiong length.

3% Humidity-Temp 20k Sensor * Wall mount humidity sensor with 20K NTC temperature sensor. 18-40 VDC or 24 VAC supply. 0-10VDC, 0-5VDC or 4-20 mA output. 3%RH accuracy REPLACED BY: H7735A2012

Humidistat spst, range 10-60%, white, duct mount or wall mount, 10%switch differential, 50va @ 24vac.

Room Humidistat SPDT * Room Humidistat. Snap Acting SPDT Switch range 10-90% RH. Fixed Dif. 5%. 7.2A @ 120V 3.6A @ 240V.

Duct Humidistat. Snap Acting SPDT Switch range 15-95% RH. Fixed Dif 5%. 7.2A @ 120V 3.6A @ 240V.

Humidity Transmitter with Temperature Sensor, Wall Mount, 1000 Ohm Thin Film Nickel Sensing Element, plus or minus 3 % Humidity Accuracy, No Setpoint Adjustment Override, 14 to 30 Vdc or 20 to 30 Vac

Enthalpy Control * Enthalpy Control Snap Acting SPDT Switch range 10-80% RH/88-59F. Fixed Dif. 8% / 2F 2.5A @ 24V. Closes Fresh Air Damper To Minimum Position When Free Cooling Is Not Available.

Enthalpy Controller w/o Box * Enthalpy control. 24 volts. SPDT. 4 position switch adjustment.

Wall Mount Humidistat * Room Humidistat. Snap Acting SPDT Switch range 10-90% RH. Fixed Dif. 4%. 6A @ 120V. 3A @ 240V.M
