Ball Valves

Ball Valve Full Port Forged Brass 1/4 Npt 600 Psig Wog 150 Psig Steam Temperatures To 366 F (185 C)

3/8 Full Port Ball Valve * Ball Valve Full Port Forged Brass 3/8 NPT 600 PSIg Wog 150 PSIg Steam Temperatures To 366 F (185 C)

Ball Valve Full Port Forged Brass 1/2 NPT 600 PSIg Wog 150 PSIg Steam Temperatures To 366 F (185 C)

Ball Valve Full Port Forged Brass 3/4 NPT 600 PSIg Wog 150 PSIg Steam Temperatures To 366 F (185 C)

1 Full Port Ball Valve * Ball Valve Full Port Forged Brass 1 NPT 600 PSIg Wog 150 PSIg Steam Temperatures To 366 F (185 C)

1-1/4 Full Port Ball Valve * Ball Valve Full Port Forged Brass 1-1/4 NPT 600 PSIg Wog 150 PSIg Steam temperatures To 366 F (185 C)

1/2 Sweat Connection Ball Vlv * 1/2 Inch Sweat Full Port Ball Valve 600 PSI WOG 150 PSI Steam Temperature Up to 366 F

3/4 Sweat Connection Ball Vlv * 3/4 Inch Sweat Full Port Ball Valve 600 PSI WOG 150 PSI Steam Temperature Up to 366 F

1 Sweat Connection Ball Valve * 1 Inch Sweat Full Port Ball Valve 600 PSI WOG 150 PSI Steam Temperature Up to 366 F

Mounting Kit (Vertical) for M9220 and others. Includes mounting bracket, crankarm, balljoint and mounting bolts.

Ball VLV linkage M920X SR * Ball valve linkage for mounting M9203 and M9208 spring return actuators to VG1000 series 1/2 to 2 inch ball valves. Max temp 212F. Order M9000-561 insulator for water up to 284F or steam up to 15 PSI.

Thermal Barrier VG1000 * Thermal insulator used to protect ball valve actuators in high temperature and steam applications. Maximum fluid temp 284F, Max steam pressure 15 PSI.

Anti Rotation Bracket

2-1/2 Mixing Valve Body* 3-Way Water Mixing Valve. 2-1/2 Flanged cv = 63, w/ integral linkage for mounting Honeywell DCA actuators. Order Motor separately. face to Face dimensions, porting and CV ratings are equal to equivalent V5013 valve body. For use in warm, hot & cold water applications only, 50% glycol max. ***VERIFY PIPING AND HEAD ROOM TO ENSURE REPLACEMENT BODY WILL FIT. MUST USE DIRECT COUPLED ACTUATOR***

4" Mixing Valve Body* 3-Way Water Mixing Valve. 4" Flanged cv = 160, w/ integral linkage for mounting Honeywell DCA actuators. Order Motor separately. Face to Face dimensions, porting and CV ratings are equal to equivalent V5013 valve body. For use in warm, hot & cold water applications only, 50% glycol max. ***VERIFY PIPING AND HEAD ROOM TO ENSURE REPLACEMENT BODY WILL FIT. MUST USE DIRECT COUPLED ACTUATOR***

1/2npt 1.2cv SS BallValve * Ball valve. 1/2 NPT 2 way. CV 1.2. Stainless steel ball and stem. Maximum close off 200 PSI. Temperature -22 to 284F, up to 15 PSI steam. Maximum static pressure 580 PSI.

1/2 1.9CV SS BALL VALVE BODY * Ball valve. 1/2 NPT 2 way. CV 1.9. Stainless steel ball and stem. Maximum close off 200 PSI. Temperature -22 to 284F, up to 15 PSI steam. Maximum static pressure 580 PSI.

1/2 2-Way 4.7cv SS Ball Valve * Ball valve. 1/2 NPT 2 way. CV 4.7. Stainless steel ball and stem. Maximum close off 200 PSI. Temperature -22 to 284F, up to 15 PSI steam. Maximum static pressure 580 PSI.

1/2 2W 7.4cv SS BallValve * Ball valve. 1/2 NPT 2 way. CV 7.4. Stainless steel ball and stem. Maximum close off 200 PSI. Temperature -22 to 284F, up to 15 PSI steam. Maximum static pressure 580 PSI.

1/2 2W 11.7cv SS BallValve * Ball valve. 1/2 NPT 2 way. CV 11.7. Stainless steel ball and stem. Maximum close off 200 PSI. Temperature -22 to 284F, up to 15 PSI steam. Maximum static pressure 580 PSI.

3/4 2W BALL VALVE 7.4cv * Ball valve. 3/4 NPT 2 way. CV 7.4. Stainless steel ball and stem. Maximum close off 200 PSI. Temperature -22 to 284F, up to 15 PSI steam. Maximum static pressure 580 PSI.

3/4 2W 11.7Cv SS TRIM * Ball valve. 3/4 NPT 2 way. CV 11.7. Stainless steel ball and stem. Maximum close off 200 PSI. Temperature -22 to 284F, up to 15 PSI steam. Maximum static pressure 580 PSI.

1 2wy 11.7cv Ball Valve * Ball valve. 1 NPT 2 way. CV 11.7. Stainless steel ball and stem. Maximum close off 200 PSI. Temperature -22 to 284F, up to 15 PSI steam. Maximum static pressure 580 PSI.

Ball valve 1 NPT 18.7CV 2 way * Ball valve. 1 NPT 2 way. CV 18.7. Stainless steel ball and stem. Maximum close off 200 PSI. Temperature -22 to 284F, up to 15 PSI steam. Maximum static pressure 580 PSI.
