Motors

EC MAX RM refrigeration motor 4-25 watts, CWOSE, 115V-230V constant speed ECM, IP67 rating, input voltage sensing technology, ball bearing design for all angle mounting, 1550 RPM, AMPS 0.1-0.56/0.06-0.34 60/50 Hertz, SHAFT DIMENSION 1/4 X 1/2, length less shaft 3".

EC MAX RM refrigeration motor 4-25 watts, CWSE, 115V-230V constant speed ECM, IP67 rating, input voltage sensing technology, ball bearing design for all angle mounting, 1550 RPM, AMPS 0.1-0.56/0.06-0.34 60/50 Hertz, SHAFT DIMENSION 1/4 X 1/2, length less shaft 3".

EC MAX Refrigeration Motor, Reversible, 1550 RPM w/ 90-Degree Plug (115/230V), 4-25 watts, 115V-230V constant speed ECM, IP67 rating, input voltage sensing technology, ball bearing design, 1550 RPM, AMPS 0.1-0.56/0.06-0.34 60/50 Hertz,shaft dimension 1/4" dia. X 1/2" length, 16" leads.

DD Mtr 115V 1/6-1/2HP 1075RPM * DIR.DRIVE MOTOR; 1/2HP; 115V; 7.3 AMPS 1100 RPM; 4 SP; ELEC.REV.; 5.6 DIA; PSC 10/370V CAP; 1/2 X 5 SHAFT; ANY ANGLE MOUNT; SLEEVE BEARINGS; OPEN VENTILATED; 17 LBS.; REPL, 1/6,1/4,1/3HP

DD Mtr 208/230V 1/2HP 1075RPM * DIR.DRIVE MOTOR; 1/2HP; 208-230V; 3.6AMP1100 RPM; 4 SP; ELEC.REV.; 5.6 DIA; PSC 10/370V CAP; 1/2 X 5 SHAFT; ANY ANGLE MOUNT; SLEEVE BEARINGS; OPEN VENTILATED; 17 LBS.; REPL, 1/6,1/4,1/3HP

CF Mtr 208/230V 1/3HP 1075RPM * COND.FAN MOTOR; 1/3HP; 208-230V; 2.6AMP 1110 RPM; 2SP; ELEC.REV.; 5.6 DIA; PSC 5/370V CAP; 1/2 X 5 SHAFT; ANY ANGLE MOUNT; BALL BEARINGS; TOTALLY ENCLOSED; 15LBS.; REPL 1/6,1/4,1/3 HP

CF Mtr 208/230V 1/3HP 825RPM * COND. FAN MOTOR; 1/3-1/6HP; 208-230V; 1.9AMP; 825 RPM; 2SP; ELEC.REV.; 5.6 DIA.; PSC 7.5/370 CAP; 1/2 X 5 SHAFT; ANY ANGLE MOUNT; BALL BRG; TOTALLY ENCL.18 LBS.; REPL 1/6,1/5,1/4, & 1/3 HP.

CF Mtr 208/230V 1/2HP 1075RPM * COND. FAN MOTOR; 1/2-1/5HP; 208-230V; 3.0AMP; 1075 RPM; 2SP; ELEC.REV.; 5.6 DIA.; PSC 10/370 CAP; 1/2 X 5 SHAFT; ANY ANGLE MOUNT; BALL BRG; TOTALLY ENCL.18 LBS.; REPL 1/5,1/4,1/3 & 1/2 HP.

115V 1/5-3/4 HP 1075 RPM * DIR.DRIVE MOTOR; 3/4 HP; 115V; 8.1 AMPS.1075 RPM; 4 SP; ELEC.REV.; 5.6 DIA; PSC 20/370V CAP; 1/2 X 5 SHAFT; STUD/ REST RING MOUNT; BALL BRGS; AIR OVER; 21 LBS.; REPL: 1/5,1/4,1/3,1/2 & 3/4 HP

DD Mtr 208/230V 3/4HP 1075RPM * DIR.DRIVE MOTOR; 3/4 HP; 208-230V; 3.8 AMPS; 1075 RPM; 4 SP; ELEC.REV.; 5.6 DIA; PSC 20/370V CAP; 1/2 X 5 SHAFT; STUD/REST RING MOUNT; BALL BRGS; AIR OVER; 21 LBS.; REPL1/5,1/4,1/3,1/2 & 3/4

CF Mtr 208/230 3/4HP 1075RPM

115V 25Watt 1500RPM CWLE 1.1amps 1/4" Threaded Shaft x 1/2" long.
